Operating temperature:-20 ~ + 65 ° C
Permissible input voltage: DC 5-24V
Input socket: DC 2.1 / 5.5mm
Output socket: 5 pin (+ RGBW)
Controller dimensions:57 x 26 x 12 [ mm]
Number of channels:4
Power max. : 72W (12V); 144W (24V)
Current max. :6A
The way of communication with the controller: WIFI- application , works with voice assistants Alexa, Siri, Alisa, Google Assistant etc.
Functions:
- Pulse width modulation (PWM): 256 steps
- Dimming: 1-100%
- Changing the colors of light
- For the controller to work properly, it must be permanently connected to the WiFi network.
Resistance class: IP20
Material: ABS
Operating temperature:-20 ~ + 65 ° C
Permissible input voltage: DC 5-24V
Input socket: DC 2.1 / 5.5mm
Output socket: 5 pin (+ RGBW)
Controller dimensions:57 x 26 x 12 [ mm]
Number of channels:4
Power max. : 72W (12V); 144W (24V)
Current max. :6A
The way of communication with the controller: WIFI- application , works with voice assistants Alexa, Siri, Alisa, Google Assistant etc.
Functions:
- Pulse width modulation (PWM): 256 steps
- Dimming: 1-100%
- Changing the colors of light
- For the controller to work properly, it must be permanently connected to the WiFi network.
Resistance class: IP20
Material: ABS
